Panel Size

3LCD 15mm (0.59")

Light Source

Laser

Разрешение

WXGA (1280 x 800)

Light Output (Brightness) ANSI Lumens

4200 (Normal)

Контрастность

500,000:1

Объектив

Built-in

System Life (Hours)

20,000

Lens Zoom

Digital Zoom x 1.35

Lens Focus

Powered Focus

Projection Lens F Number

1.6

Throw Distance

0.488m - 0.978m (centre of glass to screen)

Distance to Width Ratio/ Throw Ratio (:1)

0.3

Размер изображения по диагонали

60 - 130"

Цифровая коррекция искажений

По горизонтали: ±5°; по вертикали: ±5°

Цифровой вход

HDMI x 2 (HDCP compliant, HDMI 1 shared with MHL)

Analogue Input

15-pin Mini D-Sub x 2, RCA Jack x 1

Video Output

15 pin Mini D-Sub x 1 (shared with analog computer input)

Аудио-вход

3.5mm Stereo Mini Jack x 3

Audio Output

3.5mm Stereo Mini Jack x 1

RS-232C Control

1 x 9-pin D-Sub

Беспроводная локальная сеть

USB-WL-5G (IEEE802.11 a/b/g/n/ac: 2.4GHz/5GHz) (Optional)

Wired LAN

RJ45 Connector x 1

USB Type A

USB Type A x 2 (PC less Presentation or Wireless adapter)

Разъем USB типа B

USB type B x 1 (USB display, or USB mouse control)

Блок питания

AC 100V-120V / AC 220V-240V (50/60Hz)

Operating Power Consumption

350W

Standby Power Consumption

Less than 0.5W

Weight

7.6Kg

Dimensions (W x H x D) (Without feet)

512 x 424 x 155mm

Noise

34dB (Normal), 28dB (Whisper)

Supplied Accessories

Remote control: HL03037, Power cable, Computer cable, User’s manual, Concise, Security label, Adapter cover, Hook metal, Screw, HDMI cable holder (x2), Cable tie (large x 1, medium x 2, small x 1), AA batteries (x2)

Дополнительные комплектующие

USB Wireless adaptor USB-WL-5G, Wall mount unit HAS-WM06 (In some buying conditions wall mount is included)

Пульт ДУ

HL03037

Warranty

20,000 hours / 5 years (whichever comes first) (for extended warranties please contact your local dealer)
